．Certificate
．UL cUL
．ETL
．3P
．Standards
．ANSI/TIA- 568-B2.1/C2
．ISO/IEC 11801 Class D/E
．EN 50173-1: 2008/2011
．IEC-60603-7-2/4
．IEC-60512-26/27-100
．EIA-310-D
．Applications
．Gigabit Ethernet
．ATM155/622
．TP-PMD
．ADSL
．ISDN
．Features
．Housing is fire-resistance ABS
．Contacts are 50u” gold-plated
．Insertion life cycles > 1000 ( Typical )
．IDC insertion life cycles >250
．Contact resistance : 20M ohm
．Current rating : 1.5Amps
．DC resistance: Max.0.1ohm
．Operating temperature: -40~+60°C
．T-568A/B wiring
．RJ 45 complies with FCC part 68 standard.
．110 IDC connector : 22~26 AWG wire
